Dell Networking S3148P 48 RJ45 10/100/1000/10000Mbps Poe maximum 30.8 W ports 2 SFP ports

Large Image : Dell Networking S3148P 48 RJ45 10/100/1000/10000Mbps Poe maximum 30.8 W ports 2 SFP ports

Product Details:

Place of Origin:	Fujian, China
Brand Name:	DELL
Model Number:	Dell Network S3148

Payment & Shipping Terms:

Minimum Order Quantity:	2 pieces
Price:	$2,600.00 - $2,760.00/pieces

Contact Now

Dell Networking S3148P 48 RJ45 10/100/1000/10000Mbps Poe maximum 30.8 W ports 2 SFP ports

Description

Private Mold:	Yes	Products Status:	Stock
Ports:	≥ 48, 48 10/100/1000/10000 Ports	Transmission Rate:	10/100/1000/10000Mbps
Function:	LACP, QoS, SNMP, Stackable, VLAN Support	Communication Mode:	Full-Duplex & Half-Duplex
Switch Capacity:	260gbps	Device Type:	Switch - 48 Ports - L3 - Managed - Stackable
Applications:	Netwoking	Uplink Ports:	2*10GB Uplink Ports

Products Description

Dell Networking S3148

The S3100 switch series provides high energy efficiency and flexibility with integrated 10 GbE uplink A highly active Gigabit Ethernet (GbE) switching solution that can achieve office and campus connectivity Advanced Layer 3 Distribution of Zone Networks. The S3100 switch series has powerful features and Line speed performance, utilizing a non blocking architecture to easily handle unexpected traffic loads. Using Classic 80PLUS certified dual built-in hot swappable power supply, achieving high availability and energy efficiency. This series of switches adopts an 84 Gbps (full duplex) high availability stack architecture, Up to 12 switches can be managed through a single IP address, providing easy management Functionality and scalability.

Dell Networking S3100 Series

Using familiar tools and practices

All S3100 switches are equipped with Dell Networking OS9, which simplifies deployment and Improve interoperability. The common Command-line interface (CLI) uses well-known command language Words can help shorten the learning cycle of network administrators.

Rest assured for deployment of any size

The S3100 series switch has a data rate of up to 260 Gbps (full duplex) and forwarding speed The rate can reach up to 193 Mpps, which is sufficient to ensure performance.

Utilizing built-in post stack ports to implement Easy to expand now. Seamless redundancy can be achieved using a highly available stack architecture High density aggregation of availability for managing up to 624 ports through a single screen Switch stack.

Specification

Physical specifications	2 post stack ports (21 Gbps) supporting up to 84 Gbps (full duplex) 2 integrated 10 GbE SFP+front dedicated ports Out-of-band management port (10/100/1000BASE-T) USB (Class A) port, supporting configuration through USB flash drive Automatic negotiation enables speed and flow control Automatic MDI/MDIX, port mirroring Each port setting complies with the Energy-Efficient Ethernet standard Redundant variable speed fan Air circulation: I/O to power supply RJ45 console/management port using RS232 signal (including cable from RJ-45 to DB-9 female connector) On board dual firmware image Switching engine model: storage and forwarding
performance	MAC address count: 56K (80K in Layer 2 expansion mode) Number of Static routing: 16K (IPv4)/8K (IPv6) Number of Dynamic routing: 16K (IPv4)/8K (IPv6) Switch fabric capacity: 212 Gbps (S3124, S3124F, and S3124P) (full duplex) 260 Gbps (S3148 and S3148P) Forwarding rate: 158 Mpps (S3124, S3124F, and S3124P)193 Mpps (S3148 and S3148P) Link aggregation: 16 links per group, 128 groups in total Number of priority queues per port: 8 Line speed Layer 2 switching: All(non blocking) Line speed Layer 3 routing: All (non blocking) Flash memory: 1 GB Packet buffer memory: 4 MB CPU memory: 2 GB DDR3 Layer 2 VLAN count: 4000 MSTP: 64 instances VRF Lite: 511 instances Line speed Layer 2 switching: All protocols, including IPv4 and IPv6 Line speed Layer 3 routing: IPv4 and IPv6 IPv4 host tablesize: 22000 (in Layer 3 extended host mode: 42000) IPv6 host table size: 16000 (global and local links) (in 32000 in Layer 3 Extended Host Mode) IPv4 multicast table size: 8000 LAG load balancing: based on Layer 2, IPv4, or IPv6 headers
IEEE Compliance	802.1AB LLDP 802.1D bridging, STP 802.1p L2 prioritization 802.1Q VLAN tagging, dual VLAN tagging, GVRP 802.1Qbb PFC 802.1Qaz ETS 802.1s MSTP 802.1w RSTP 802.1X Network Access Control 802.1X Network Access Control 802.1x-2010 Port Based Network Access Control 802.3ab Gigabit Ethernet (1000BASE-T) 802.3ac VLAN Tag Frame Extension 802.3ad LACP compliant Link aggregation 802.1ax Link aggregation version – 2008 and 2011 802.3ae 10 Gigabit Ethernet (10GBASE-X) 802.3af PoE (applicable to S3124P and S3148P) 802.3at PoE+(applicable to S3124P and S3148P) 802.3az Energy-Efficient Ethernet (EEE) 802.3u Fast Ethernet (100BASE-TX) (Management Port) 802.3x flow control 802.3z Gigabit Ethernet(1000BASE X) ANSI/TIA-1057 LLDP-MED Force10 PVST+ MTU 12000 bytes

Dell PowerSwitch S3148P

* Manufacturer: Dell * Model: S3148P
* Switch Size: 1 RU * Ports: 48 x 1000Mb POE+
