Upgrade Your Data Storage System with Dell Unity XT 380 Hybrid Flash Array and Solution

Upgrade Your Data Storage System with Dell Unity XT 380 Hybrid Flash Array and Solution
Upgrade Your Data Storage System with Dell Unity XT 380 Hybrid Flash Array and Solution Upgrade Your Data Storage System with Dell Unity XT 380 Hybrid Flash Array and Solution Upgrade Your Data Storage System with Dell Unity XT 380 Hybrid Flash Array and Solution Upgrade Your Data Storage System with Dell Unity XT 380 Hybrid Flash Array and Solution Upgrade Your Data Storage System with Dell Unity XT 380 Hybrid Flash Array and Solution Upgrade Your Data Storage System with Dell Unity XT 380 Hybrid Flash Array and Solution

Large Image :  Upgrade Your Data Storage System with Dell Unity XT 380 Hybrid Flash Array and Solution

Product Details:
Place of Origin: China
Brand Name: DELL
Model Number: Unity Xt 380
Payment & Shipping Terms:
Minimum Order Quantity: 2 pieces
Price: $29,800.00 - $48,800.00/pieces
Packaging Details: BOX
Supply Ability: 5000 Piece/Pieces per Month
Contact Now

Upgrade Your Data Storage System with Dell Unity XT 380 Hybrid Flash Array and Solution

Description
Private Mold: NO Products Status: Stock
Interface Type: ESATA, Port RJ-45, Usb Maximum Capacity:: Maximum Capacity:
Dimension: 8.7*48.2*54.1cm Brand Name:: DELL
Voltage: 100-240VAC; 48V DC Port: Tianjin Guangzhou

Details Images
Upgrade Your Data Storage System with Dell Unity XT 380 Hybrid Flash Array and Solution 0
Overview:
* Unified block, file, and VMware VVols support
* Delivers up to 2.4PB max raw capacity
* Includes inline data reduction (all flash pools)
* Protects investment with the Future-Proof Program (support agreement required)
Ideal for the remote, branch office (ROBO) and midmarket, Dell EMC Unity XT 380 hybrid flash is the entry point to the Dell EMC Unity XT hybrid storage series. It provides simple and affordable unified storage that is designed for performance to deliver high-speed access to business data with the ability to simultaneously run mixed application workloads, process inline data reduction, and provide data services with no performance overhead.
Dell EMC Unity XT 380 is also optimized for efficiency with inline data reduction to deliver outstanding TCO, starting in a small 2U footprint. Plus, you will be able to enable your multi-cloud strategy whether you are looking for disaster recovery as a service in the cloud, integration with VMware Cloud Foundation, deploying storage in the cloud, or automatically tiering data to the cloud.
Benefit from point-in-time snapshots, local and remote data replication, built-in encryption, and deep integration with
VMware,Microsoft, and OpenStack. Automated tiering and flash caching place data on the appropriate tier of storage for the highest system performance at the lowest storage cost.
Gain intelligent insight into your storage health with CloudIQ, which provides cloud-based proactive monitoring and predictive analytics. Additionally, ongoing operation is simple with proactive assistance and automated remote support.

Upgrade Your Data Storage System with Dell Unity XT 380 Hybrid Flash Array and Solution 1
Upgrade Your Data Storage System with Dell Unity XT 380 Hybrid Flash Array and Solution 2
Specification
380F/380
480F/480
680F/680
880F/880
Min/Max Drive Count
Min. 6 SSDs or 10 HDDs / Max. 500
Min. 6 SSDs or 10 HDDs / Max. 750
Min. 6 SSDs or 10 HDDs / Max. 1000
Min. 6
SSDs or 10 HDDs / Max. 1500
Array Enclosure
A 2U Disk Processor Enclosure (DPE) with twenty-five 2.5” drives
Drive Enclosure (DAE - Disk Array Enclosure)
All-Flash (F) models support 2.5” drives in the 2U twenty-five drive tray. Hybrid models support 2.5“drives in 2U twenty-five
drive and 3.5” drives in 3U fifteen drive trays.
Standby Power System
Dell Unity systems are powered by 2 power supplies (PS) per DPE/DAE. Each power supply can provide power to the entire module if
the peer PS has been removed or is faulted. DPE power during a power failure is provided by a Battery Back Up (BBU) module. BBU is
located within the SP enclosure and provides power to a single module (power zone)
RAID Options
1/0, 5, 6
CPU per Array
2 x Intel CPUs, 12 cores per Array, 1.7GHz
2 x dual-socket Intel CPUs, 32 cores per Array, 1.8GHz
2 x dual-socket
Intel CPUs, 48 cores per Array, 2.1GHz
2 x dual-socket Intel CPUs 64 cores per Array, 2.1GHz
System Memory/Cache per Array
128 GB
192 GB
384 GB
768 GB
Max FAST Cache per Array*
Up to 800 GBs
Up to 1.2 TBs
Up to 3.2 TBs
Up to 6.0TBs
Total CacheA
Up to 928 GBs
Up to 1.39 TBs
Up to 3.58 TBs
Up to 6.76 TBs
Max Mezzanine cards per ArrayB
NA
2
2
2
Max IO Modules per ArrayC
4
4
4
4
Embedded SAS IO Ports per Array
4 x 4 lane 12Gb/s SAS ports for BE (back end) Connection
4 x 4 lane 12Gb/s SAS ports for BE
Connection
4 x 4 lane 12Gb/s SAS ports for BE Connection
4 x 4 lane 12Gb/s SAS ports for BE Connection
Optional SAS IO ports per Array
NA
8 x 4 lane or 4 x 8 lane 12Gb/s SAS ports (for BE Connection)
8 x 4 lane or 4 x 8 lane 12Gb/s
SAS ports (for BE Connection)
8 x 4 lane or 4 x 8 lane 12Gb/s SAS ports (for BE Connection)
Base 12 Gb/s SAS BE Buses per Array
2 x 4 Lane
2 x 4 Lane
2 x 4 Lane
2 x 4 Lane
Max 12 Gb/s SAS BE Buses per Array
2 x 4 Lane
6 x 4 Lane; or 2 x 4 lane and 2 x 8 lane
6 x 4 Lane; or 2 x 4 lane and 2 x 8 lane
6
x 4 Lane; or 2 x 4 lane and 2 x 8 lane
Max FE (front end) Total Ports per Array (all types)
20
24
24
24
Max Initiators per Array
1,024
2,048
2,048
4,096
Max FC Ports per Array
20
16
16
16
Embedded 10GbaseT Ports per Array
NA
NA
NA
NA
Product Paramenters
Upgrade Your Data Storage System with Dell Unity XT 380 Hybrid Flash Array and Solution 3
Upgrade Your Data Storage System with Dell Unity XT 380 Hybrid Flash Array and Solution 4
Company Profile
Beijing Zhongsheng Huijia Trading Co., Ltd was established in 2014 in Beijing. The company is mainly engaged in Dell EMC, Lenovo, HP, Inspur and Huawei, including server, workstation, storage, IT system integrator sales ,wholesale, retail and after-sales business.  Large amount yearly turnover makes us become the Platinum Partner of Dell and Lenovo . The company has more than 200 channel sales and after-sales service staff, and channels throughout Chinese mainland. Our company operates a rich product line, covering a wide range of desktops, laptops, all-in-one computers, servers, network products, storage products, software, peripherals and so on. Over the years, the company also provides a variety of information technology solutions for customers in many industries, such as government agencies, education, enterprises, finance, post and telecommunications, military, medical and other industries. the company has accumulated rich industry experience in demand analysis, technical demonstration, equipment selection, network implementation, quality assurance, operation and maintenance, service support and so on.
Upgrade Your Data Storage System with Dell Unity XT 380 Hybrid Flash Array and Solution 5
Why Choose Us
Upgrade Your Data Storage System with Dell Unity XT 380 Hybrid Flash Array and Solution 6
Upgrade Your Data Storage System with Dell Unity XT 380 Hybrid Flash Array and Solution 7
Warehouse
Upgrade Your Data Storage System with Dell Unity XT 380 Hybrid Flash Array and Solution 8
Upgrade Your Data Storage System with Dell Unity XT 380 Hybrid Flash Array and Solution 9
Upgrade Your Data Storage System with Dell Unity XT 380 Hybrid Flash Array and Solution 10
Upgrade Your Data Storage System with Dell Unity XT 380 Hybrid Flash Array and Solution 10
Transportation
Upgrade Your Data Storage System with Dell Unity XT 380 Hybrid Flash Array and Solution 12
Upgrade Your Data Storage System with Dell Unity XT 380 Hybrid Flash Array and Solution 13
FAQ
Q1.How about the delivery time if order ? A:We have large spot stock, generally can ship within 1-2 working days. Q2. 24-hour online service? A:Email / Mobile / Skype / Whats app all are 24 hours available since you need. Q3. Do you offer product warranty? A: Yes, our products provide 1 year warranty and long-term technical support. Q4.How about the package ? A:Carton or wooden box if need . Q5.How to pay ? A:We accept T/T, Alibaba trade assurance , Western Union and so on . Q6. Are your machines new or used ? A:All of our goods are new.
