Product Details:
|
Products Status: | Stock, Stock | Type: | Rack |
---|---|---|---|
Processor Type: | Intel Xeon Gold 6338N | Warranty: | 3 Years |
Processor | One 3rd Generation Intel Xeon Scalable processor with up to 36 cores |
Memory | • Eight DDR4 DIMM slots, supports RDIMM 512 GB max or LRDIMM 1 TB max, speeds up to 3200 MT/s • Up to four Intel Optane PMem 200 Series slots, 512 GB max • Supports registered ECC DDR4 DIMMs only |
Storage controllers | • Internal controllers (RAID): PERC H755, S150 • Internal Boot: Boot Optimized Storage Subsystem (BOSS-S1): HWRAID 2 x M.2 SSDs or USB • External PERC (RAID): PERC H840 • 12 Gbps SAS HBAs (non-RAID): internal- HBA355i, external-HBA355e |
Drive bays | 4 x 2.5-inch SATA/SAS/NVMe (SSDs) max 61.44 TB |
Power supplies | • 1400 W Platinum AC/240 HVDC • 1100 W DC/-48 - (-60) V • 800 W Platinum AC/240 HVDC |
Cooling options | Air cooling |
Fans | Very High Performance fans • Six cold swap fans |
Dimension | • Height: 42.8 mm (1.68 inches) • Width: 482.6 mm (19 inches) • Depth: 400 mm (15.74 inches) Ear to rear wall 477 mm (18.77 inches) with bezel • 463 mm (18.22 inches) without bezel |
Form Factor | 1U rack server |
Embedded management | • iDRAC9 • iDRAC Direct • iDRAC Service Module |
Bezel | Optional bezel or security bezel |
OpenManage Software | • OpenManage Enterprise • OpenManage Power Manager plugin • OpenManage SupportAssist plugin • OpenManage Update Manager plugin |
Mobility | OpenManage Mobile |
Integrations and Connections | • BMC Truesight • Microsoft System Center • Red Hat Ansible Modules VMware vCenter and vRealize Operations Manager |
Security | • Cryptographically signed firmware • Secure Boot • Secure Erase • Silicon Root of Trust • System Lockdown (requires iDRAC9 Enterprise or Datacenter) • TPM 2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ |
Embedded NIC | 4 x 25 GbE SFP+ LOM |
GPU options | 2 x 70 W SW |
Ports | Front Ports • 1 x iDRAC Direct (Micro-AB USB) port 1 x USB 2.0 |
For Front Accessed configuration | |
Front Ports • 1 x USB 2.0 • 1 x iDRAC dedicated port • 1 x USB 3.0 • 1 x Serial port • 1 x VGA 1 x iDRAC Direct (Micro-AB USB) port | |
PCIe | 3 x PCIe Gen4 slots |
Operating System and Hypervisors | • Canonical Ubuntu Server LTS • Citrix Hypervisor • Microsoft Windows Server with Hyper-V • Red Hat Enterprise Linux • SUSE Linux Enterprise Server • VMware ESXi • RHEL Realtime |
