12th generation Intel ®core i9-12900Kjol 30 MB cache, 16 cores.
(8P+8E), 3.2 GHz to 5.2 GHz,125 W.
12th generation Intel ®core i9-12900 MB 30 caches, 16 cores.
(8P+8E), 2.4 GHz to 5.1 GHz,65 W.
12th generation Intel ®Core i7-12700KPhone25 MB cache, 12 cores.
(8P+4E), 3.6GHz to 5.0GHz,125 W.
12th generation Intel ®core i7-12700 MB 25 cache, 12 cores.
(8P+4E), 2.1 GHz to 4.9 GHz,65 W.
12th generation Intel ®Core i5-12600K Magee 20 MB cache, 10 cores.
(6P+4E), 3.7 GHz to 4.9 GHz,125 W.
12th generation Intel ®Core i5-12600 18 MB cache, 6 cores.
(6P+0E), 3.3GHz to 4.8GHz,65 W.
12th generation Intel ®Core i5-12500 18 MB cache, 6 cores.
(6P+0E), 3.0 GHz to 4.6 GHz,65 W.
12th generation Intel ®Core i3-12100jue 12 MB cache, 4 cores.
(4P+0E), 3.3 GHz to 4.3 GHz,60 W27,28.
Note: all processors come with Intel ®integrated graphics cards.
Processor cooling options 29, 30.
1. Standard CPU air cooling system (for up to 65 W CPU).
two。. Advanced CPU Air cooling system (for all CPU).
3. High-end CPU liquid cooling system (for all CPU)Memory option
4 DIMM slots: up to 128 GB or up to 4400 MHz ECC and non.
ECC DDR5.
Maximum speed: 4400 MHz.
Maximum capacity: 128 GB.
The maximum memory speed varies depending on the following configuration on each channel. If 2 DIMM.
If the configuration is asymmetrical, the maximum speed may decrease.
4400 MHz:1 DIMM-1R/2R.
4000 MHz:2 DIMM-1R.
3600 MHz:2 DIMM-2R.
8 GB (1 x 8 GB), DDR5,4400 MHz, non-ECC.
16 GB (2 x 8 GB), DDR5,4400 MHz, non-ECC, dual channel.
32 GB (2 x 16 GB), DDR5,4400 MHz, non-ECC, dual channel.
64 GB (2 x 32 GB), DDR5,4400 MHz, non-ECC, dual channel.
32 GB (4 x 8 GB), DDR5,4000 MHz, non-ECC, dual channel.
64 GB (4 x 16 GB), DDR5,4000 MHz, non-ECC, dual channel.
128 GB (4 x 32 GB), DDR5,3600 MHz, non-ECC, dual channel.
16 GB (1 x 16 GB), DDR5,4400 MHz,ECC.
32 GB (2 x 16 GB), DDR5,4400 MHz,ECC, dual channel.
64 GB (2 x 32 GB), DDR5,4400 MHz,ECC, dual channel.
64 GB (4 x 16 GB), DDR5,4000 MHz,ECC, dual channel.
128 GB (4 x 32 GB), DDR5,3600 MHz,ECC, dual channel 31
Storage
Supports up to 3 M.2 2280 PCIe NVMe SSD and up to 3 on the motherboard. X 3.5in SATA33, 34x or 4x 2.5in SATA HDD. Specific storage configurations provide 2.5in SATA or 3.5in removable from the front. SATA HDD (with lockable cover and key). Support for Intel ®ready mode resume technology. Up to 1 add-on can be supported on active cooling Dell Precision ultra-high speed drives. PCIe SSD. RAID 0Accord 1Compact 5Compact 10. M.2 2230256 GB,PCIe NVMe ®Class 35 SSD. M.2 2280512 GB,PCIe NVMe ®Class 40 SSD. M.2 2280J 1 TB,PCIe NVMe ®Class 40 SSD. M.2280jue 2 TB,PCIe NVMe ®Class 40 SSD. M.2 2280jue 4 TB,PCIe NVMe ®Class 40 SSD. M.2 2280512 GB,PCIe NVMe ®SSD, self-encrypting driv. M.2 2280J1 TB,PCIe NVMe ®SSD, self-encrypting drive. 2.5 ", 500 GB,7200 RPM,SATA,HDD. 2. 5 "500 GB,7200 RPM, self-encrypting, Opal 2. 0 feeds, SATA, and HDD. 2.5 ", 1 TB,7200 RPM,SATA,HDD. 3. 5 ", 1 TB,7200 RPM,SATA,HDD. 3. 5 ", 2 TB,7200 RPM,SATA,HDD. 3. 5 ", 4 TB,5400 RPM,SATA,HDD. 3. 5 "4 TB,7200 RPM,SATA, enterprise HDD. 3. 5 ", 8 TB,7200 RPM,SATA, enterprise HDD32
Video card option
Intel ®UHD graphics card 730 for the 12th generation Kuiri i3 processor.
Intel ®UHD graphics card 770 for the 12th generation Kerry i5/i7/i9 processor.
NVIDIA ®RTX A6000 Magazine 48 GB,GDDR6.
AMD Radeon examples Pro W6800, 32 GB,GDDR6.
NVIDIA ®RTX A5000 Magazine 24 GB,GDDR6.
NVIDIA ®RTX A4000JI 16 GB,GDDR6.
AMD Radeon Pro RX6900XT,16 GB,GDDR6.
AMD Radeon watches Pro W6600 8 GB,GDDR6.
NVIDIA ®RTX A2000 Magi 6 GB,GDDR6.
AMD Radeon Pro WX3200,4 GB,GDDR5.
NVIDIA ®T1000BI 4 GB,GDDR6.
NVIDIA ®T600, 4 GB,GDDR6.
NVIDIA ®T400, 2 GB,GDDR6
